Brass Mortise Ball Bearing Flat Tip Hinge

Ball Bearing Flat Tip Hinges.

  • 2 bearing can be in the middle or at the ends of the barrel.
  • All decorative finials are interchangeable.
  • 5,00,000 opening/closing cycles tested.
  • Suitable for 35mm to 55mm thick door upto 120kg of door weight
  • Can go very well with /without all type of door closers.

This product is currently out of stock and unavailable.

Make an enquiry
Add to Wishlist

                                            Size Chart

Code Hinges Size Hinges Size
in inch in mm
L X W X T L X W X T
1100FF 3″ x 2.1/2″ x 3mm 76 x 64 x 3
1104FF 4″ x 3″ x 3mm 102 x 76 x 3
1105FF 4″ x 3″ x 4mm 102 x 76 x 4
1106FF 4″ x 3.1/2″ x 3mm 102 x 89 x 3
1107FF 4″ x 3.1/2″ x 4mm 102 x 89 x 4
1114FF 5″ x 3″ x 3mm 127 x 76 x 3
1115FF 5″ x 3″ x 4mm 127 x 76 x 4
1131FF 5″ x 3″ x 5mm 127 x 76 x 5
1116FF 5″ x 3.1/2″ x 3mm 127 x 89 x 3
1117FF 5″ x 3.1/2″ x 4mm 127 x 89 x 4
1118FF 5″ x 3.1/2″ x 5mm 127 x 89 x 5
1124FF 5″ x 5″ x 5mm 127 x 127 x 5
1143FF 6″ x 3.1/2″ x 3mm 152 x 89 x 3
1137FF 6″ x 3″x 4mm 152 x 76 x 3
1138FF 6″ x 3.1/2″ x 4mm 152 x 89 x 4
1132FF 6″ x 3″x 5mm 152 x 76 x 5
1125FF 6″ x 4″ x 5mm 152 x 102 x 5
1126FF 6″ x 3.1/2″x 5mm 152 x 89 x 5
1144FF 8″ x 3″ x 5mm 203 x 76 x 5
1139FF 8″ x 3.1/2″x 5mm 203 x 89 x 5
1127FF 6″ x 5″ x 5mm 152 x 127 x 5
1133FF 6″x 6″ x 5mm 152 x 152 x 5
1128FF 8″ x 5″ x 5mm 203 x 127 x 5
1142FF 10″ x 3.1/2″x 5mm 254 x 89 x 5
1129FF 10″ x 5″ x 5mm 254 x 127 x 5
1141FF 12″ x 3.1/2″x 5mm 305 x 89 x 5
1130FF 12″ x 5″ x 5mm 305 x 127 x 5
